Open Access 14-08-2018 | Heart Beat

Apical sparing of longitudinal strain in speckle-tracking echocardiography

A sensitive and specific finding in cardiac amyloidosis

Auteurs: J. Gil, L. Abreu, H. Antunes, M. L. Gonçalves, M. I. Pires, D. Moreira, E. Correia, L. S. Santos, J. C. Cabral

Gepubliceerd in: Netherlands Heart Journal | Uitgave 12/2018

share
DELEN

Deel dit onderdeel of sectie (kopieer de link)

  • Optie A:
    Klik op de rechtermuisknop op de link en selecteer de optie “linkadres kopiëren”
  • Optie B:
    Deel de link per e-mail
insite
ZOEKEN
A 47-year-old man was admitted for acute heart failure. The ECG had low voltage criteria. Transthoracic echocardiogram showed bi-atrial dilation, left ventricular concentric hypertrophy with reduced ejection fraction (LVEF of 48%) and hypertrophy of the right ventricular free wall. There was no valve dysfunction. Two-dimensional speckle-tracking echocardiography showed an apical sparing pattern of longitudinal strain (Fig. 1). Electrophoresis of serum proteins and bone marrow biopsy confirmed multiple myeloma. This suggested AL-type amyloidosis, and abdominal fat biopsy demonstrated amyloid-like, birefringent substance deposition in polarised light. Chemotherapy was started, remission occurred, and the patient remained stable after over 3 years of follow-up.
Amyloidosis is a multi-systemic disease characterised by the deposition of amyloid fibrils, cardiac involvement being usually associated with poor prognosis [1, 2]. Relative sparing of longitudinal strain in the left ventricular apex, which may be related to less amyloid deposition occurring in the apex than in the base, is highly sensitive and specific for the diagnosis of cardiac amyloidosis [1, 2].

Conflict of interest

J. Gil, L. Abreu, H. Antunes, M.L. Gonçalves, M.I. Pires, D. Moreira, E. Correia, L.S. Santos and J.C. Cabral declare that they have no competing interests.
Open Access This article is distributed under the terms of the Creative Commons Attribution 4.0 International License (http://​creativecommons.​org/​licenses/​by/​4.​0/​), which permits unrestricted use, distribution, and reproduction in any medium, provided you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons license, and indicate if changes were made.
share
DELEN

Deel dit onderdeel of sectie (kopieer de link)

  • Optie A:
    Klik op de rechtermuisknop op de link en selecteer de optie “linkadres kopiëren”
  • Optie B:
    Deel de link per e-mail

Onze productaanbevelingen

Netherlands Heart Journal

Het Netherlands Heart Journal wordt uitgegeven in samenwerking met de Nederlandse Vereniging voor Cardiologie. Het tijdschrift is Engelstalig en wordt gratis beschikbaa ...

Literatuur
1.
go back to reference Phelan D, Collier P, Thavendiranathan P, et al. Relative apical sparing of longitudinal strain using two-dimensional speckle-tracking echocardiography is both sensitive and specific for the diagnosis of cardiac amyloidosis. Heart. 2012;98:1442–8.CrossRef Phelan D, Collier P, Thavendiranathan P, et al. Relative apical sparing of longitudinal strain using two-dimensional speckle-tracking echocardiography is both sensitive and specific for the diagnosis of cardiac amyloidosis. Heart. 2012;98:1442–8.CrossRef
2.
go back to reference Liu D, Hu K, Nordbeck P, Ertl G, Störk S, Weidemann F. Longitudinal strain bull’s eye plot patterns in patients with cardiomyopathy and concentric left ventricular hypertrophy. Eur J Med Res. 2016;21:21.CrossRefPubMed Liu D, Hu K, Nordbeck P, Ertl G, Störk S, Weidemann F. Longitudinal strain bull’s eye plot patterns in patients with cardiomyopathy and concentric left ventricular hypertrophy. Eur J Med Res. 2016;21:21.CrossRefPubMed
